110V - 690V Single Phase AC Generator Brushless Synchronous 45kw / 45KVA

Name: 110V 690V Single Phase AC Generator Brushless Synchronous 45kw 45KVA
Brand: WERNA
Price: 880 USD

Brand Name : WERNA

Model Number : WR224E16

Certification : CE,ISO9001,SASO

Place of Origin : Wuxi,China

MOQ : 1 pcs

Price : USD 880 FOB SHANGHAI

Payment Terms : T/T, L/C

Supply Ability : 1000 units/month

Delivery Time : 15 days

Packaging Details : Plywood

Wire : 100% copper wire

Life time : 20 years

Warranty : 2 years

THF : <2%

Insulation class : H

Protection : IP22/23

Contact Now

110V - 690V Single Phase AC Generator Brushless Synchronous 45kw / 45KVA

Quick Detail:

Name	ALTERNATOR	Brand Name	WERNA
Color	According to the international standard color card	Feature	AC brushless synchronous excitation alternator
Power	45kw	Certificate	CE,ISO9001,SASO

Specifications:

Model	WR224E16
manufacturer	Wuxi City ,Jiangsu Prov ,China making alternators
Output Type	AC Single Phase diesel generator
Terminal	12 / 6 Wire
Rated Voltage	110-240V
Frequency	60HZ
Speed	1800RPM
Mounting dimensions	Stamford Type
Winding Pitch	2 / 3 pitch
Excitation	Brushless, self-excited, synchronous
Insulation Class	H

Description:
Copy Stamford brushless alternators we supply:
● Power range: from 8kva to 1250kva
● 100% copper &100% output
● Real H class insulation
● IP22 protection
● Whole piece silicon plate

Frequency And Voltage
50Hz or 60Hz as per customer’s request. Voltage from 380 ~ 690V, 190V~345V, 220~400V, serial star, parralle star and serial delta connection are available, All three-phase generators are 12-lead reconnectable, providing voltage and phase flexibility.

Insulation and Protection
Insulation: H, Protection: IP22

Voltage Regulators
The model we use including: MX321, MX341, AS440, SX440, SX460, etc.

Winding
All generator stators are wound to 2/3 pitch.
We have got ISO & CE, and our alternators are widely exported to the world-wide market, like Southeast Asia, Middle East, Africa and South American countries etc. Our products are well-received by our customers.

Competitive Advantage:
1. 100% copper winding wire
2. In stock and fast delivery
3. Two year warranty
4. Best quality and competitive price
5. Two-time vacuum impregnation dipping
6. powerful quality control team
7. CE,ISO9001
8. Good after-sale service
